KISHAN Chain Sharpener Machine

KISHAN Chain Sharpener Machine

Features

ADJUSTING SCALE A.B.C.
For	SCALE			Position of Pawl
	A	B	C	Behind the cutter to be sharpened
Left hand Cutter	40	-15°	-35°
Right hand Cutter	40	15°	35°
Depth Gauge	40	0	0

Scale A:

It for setting the top plate cutting angle lessen the Hex nut m-10 set on the (+400) fixed mark of CIRCULAR BASE against the zero line in the main base.

Scale B:

It is for centering the chain cutters to be sharpened, Loosen the wing nut M-8 at the bottom of the main base, set the zero line of SLIDING PLATE against the required degree mark (-150 or +150) in the main base.

Scale C:

It is the setting the top plate angle. loosen the wing nut M-8 at bottom of the sliding plate and set the required degree mark (-350 or +350) of protector against the zero line in sliding plate.
